RA202

MATERIALS

• AISI 304 stainless steel

SUITABLE FOR

• Riverclack® 500
• Riverclack® 550
• Riverclack® 600

INCLUDED COMPONENTS

• N° 2 M8 x 20 stainless steel, hexagon profile stainless steel screw bolt
• N° 2 hexagon profile stainless steel self-locking nuts
• N° 4 8/24 stainless steel washers

RELATED COMPONENTS

• N° 1 polyamide clip

NOTES

• Associated polyamide clip is not to be fixed to the purlins
• Keep the related polyamide clip at least 60 mm away from any fixing clip
• Don't install on the protruding end zones of the panel
• It is always highly recommended that the design is carried out by a competent technician, beware of loads caused by extreme weather conditions
